01 Set your reference Use the zero reference, north arrow, and snap options to line the tool up with the structure you are checking.
02 Place and label pipes Track pipe locations with visual labels, colors, and dynamic angle readings so the layout stays clear.
03 Check the angle Switch between round and rectangular modes, then use snap increments to make repeated checks faster.
Precision Angle Measurement Real-time angle display with 1° precision. Round and rectangular measurement modes. Primary angle snapping for 0°, 90°, 180°, and 270°. Custom snap increments from 1° to 90°.
Smart Pipe Management Unique pipe colors and numbers for quick identification. Auto-outpipe placement at 0° on startup. Up to 16 pipe placements with drag-and-drop positioning. Pipe zero mode for relative angle measurements.
Round and Rectangular Modes Absolute angle measurements from a 0° reference. Traditional circular protractor behavior for round layouts. Rotation mode for rectangular structures. Independent protractor rotation for precise positioning.
